Material Handling Hose | Parker SS225 Series

    Material Handling Hose - 1/4" SBR Tube - Series SS225


    Series SS225 is a lightweight, medium pressure discharge hose for dry abrasive materials such as cement and powders. The static dissipating 1/4" SBR tube provides abrasion resistance and the SBR cover is resistant to abrasion, cuts, scuffs and weathering.

    Parker Material Handling Hose Sizes & Specifications

    • Tube: 1/4" Black SBR; static dissipating
    • Reinforcement: Multiple textile plies
    • Cover: Black SBR; wrapped finish
    • Temp. Range: -40°F to +180°F (-40°C to +82°C)
    • Brand Method: Black text on blue stripe
    • Brand Example: PARKER SERIES SS225 MATERIAL HANDLING HOSE XXX PSI WP 1/4" TUBE MADE IN USA
    • Design Factor: 4:1
    • Industry Standards: None applicable
    • Applications:  Abrasive dry materials, cement, lime, powders, silica.  In-plant transfer/loading, bulk transport trucks. Construction, general industrial.
    • Vacuum: Not recommended
    • Packaging: Coils

    Part Number

    ID

    Reinf

    Plies

    OD

    Approx Wt

    Max Rec WP

    Std Pack Qty

    in

    mm

    in

    mm

    lbs/ft

    kg/ft

    psi

    bar

    ft

    SS225-4000

    4

    101.6

    2

    4.750

    120.7

    2.61

    1.18

    125

    8.6

    100

    SS225-4500

    4-1/2

    114.3

    2

    5.250

    133.4

    2.96

    1.34

    100

    6.9

    100

    SS225-5000

    5

    127.0

    2

    5.750

    146.1

    3.28

    1.49

    100

    6.9

    100

    SS225-6000

    6

    152.4

    2

    6.750

    171.5

    3.92

    1.78

    100

    6.9

    100
