Weld/Braze On Fittings for Brake & Clutch Lines | BrakeQuip
The ultimate convenience item for aluminum tubes found on air conditioning and oil cooler lines. This problem solver will make it easy to connect aluminum tube to flexible hose.
Weld-On Fittings
Aluminum Weld-On Fittings
 |
 |
| PART NO. | THREAD | SEAT ANGLE | B | A |
| BQ170 | 9/16' x 18NF | 37˚ | 20mm | 3/8' |
| BQ171 | 5/8' x 18NF | 45˚ | 22mm | 3/8' |
| BQ172 | 3/4' x 16NF | 37˚ | 23mm | 1/2' |
| BQ173 | 7/8' x 14NF | 37˚ | 26mm | 5/8' |
| BQ174 | 1-1/16' x 14 | 45˚ | 34mm | 3/4' |
Weld-On Fittings
 |
The ultimate problem solver for connecting metal tube to hose. FEATURES: 1. Universal countersink hole for 3/16" & 1/4" tube sizes 2. Popular No. 3 JIC take off point |
Braze-On Fittings
 |
No. 6 JIC (9/16" x 18NF) male braze-on fitting for power steering tubes. |
