JIC tube fittings - straights | Parker Triple-Lok
Parker Triple-Lok JIC tube fitting design is simple. The tube fitting consists of three pieces: the body, the nut and the sleeve. The tube end is flared at a mating 37 degree angle and sandwiched between the fitting nose (seat) and the sleeve. This creates a very effective seal between the fitting nose and tube flare, or hose. Read more about how JIC fittings work.
Although most JIC fittings are commonly viewed as 3,000 PSI connectors, Parker Triple-Lok JIC flared fittings are rated at 9,000 PSI for 1/4" size to 2000 PSI for 2” size. Parker JIC 37 degree flare fittings are manufactured in steel, 316 stainless steel or brass, and are readily available through Motion & Flow Control Products, Inc.
![]() |
Parker Triple-Lok 37 degree flare fittings are manufactured in steel, 316 stainless steel and brass for optimum fluid compatibility and corrosion resistance, and are readily available through Motion & Flow Control Products, Inc.. |
Below is the list of end configurations for 37-degree JIC straight fittings (Parker Triple-Lok) available from Motion & Flow Control Products, Inc.
Scoll down to see the drawings and part numbers for the available straight JIC fittings end configurations:
