Parker MAV | BSPP Pressure Gauge Adapters (Type D)
Parker BSPP Pressure Gauge Adapters (Type D) Part #: MAV
BSPP Gauge / EO |
TUBE FITTING |
TYPE |
END SIZE |
L |
H BODY HEX (mm) |
H2 NUT HEX (mm) |
Pressure |
||
1 |
2 |
Static |
Dynamic |
|||||
S |
S |
|||||||
4-4G4MXSMO |
A |
1/4 |
1/4-19 |
31.0 |
17 |
— |
5.0 |
5.0 |
6G4MXSMO |
A |
3/8 |
1/4-19 |
28.0 |
17 |
— |
5.0 |
5.0 |
8-4G4MXSMO |
A |
1/2 |
1/4-19 |
31.0 |
19 |
— |
5.0 |
5.0 |
4-4G4MLOSMO |
B |
1/4 |
1/4-19 |
26.8 |
17 |
— |
5.0 |
5.0 |
6G4MLOSMO |
B |
3/8 |
1/4-19 |
28.2 |
19 |
— |
5.0 |
5.0 |
8-4G4MLOSMO |
B |
1/2 |
1/4-19 |
29.8 |
22 |
— |
5.0 |
5.0 |
|
|
1 (mm) |
2 BSPP |
|
|
|
Static CF |
Dynamic CF |
MAVE06LR |
C |
6 |
1/4-19 |
35.5 |
19 |
14 |
4.6 |
4.6 |
MAVE08LR |
C |
8 |
1/4-19 |
35.5 |
19 |
17 |
4.6 |
4.6 |
MAVE10LR |
C |
10 |
1/4-19 |
36.0 |
19 |
19 |
4.6 |
4.6 |
MAVE06SR |
C |
6 |
1/2-14 |
42.5 |
27 |
17 |
9.1 |
9.1 |
MAVE08SR |
C |
8 |
1/2-14 |
43.0 |
27 |
19 |
9.1 |
9.1 |
MAVE10SR |
C |
10 |
1/2-14 |
43.5 |
27 |
22 |
9.1 |
9.1 |
MAVE12SR |
C |
12 |
1/2-14 |
45.0 |
27 |
24 |
9.1 |
9.1 |
MAVE06SR1/4 |
C |
6 |
1/4-19 |
35.5 |
19 |
17 |
9.1 |
9.1 |
MAVE08SR1/4 |
C |
8 |
1/4-19 |
35.5 |
19 |
19 |
9.1 |
9.1 |
MAVE10SR1/4 |
C |
10 |
1/4-19 |
39.0 |
19 |
22 |
9.1 |
9.1 |
MAVE12SR1/4 |
C |
12 |
1/4-19 |
39.0 |
19 |
24 |
9.1 |
9.1 |
MAV04LLR |
D |
4 |
1/4-19 |
33.0 |
19 |
10 |
1.4 |
1.4 |
MAV06LR |
D |
6 |
1/4-19 |
37.0 |
19 |
14 |
4.5 |
4.5 |
MAV08LR |
D |
8 |
1/4-19 |
37.0 |
19 |
17 |
4.5 |
4.5 |
MAV10LR |
D |
10 |
1/4-19 |
38.0 |
19 |
19 |
4.5 |
4.5 |
MAV12LR |
D |
12 |
1/4-19 |
38.0 |
19 |
22 |
4.5 |
4.5 |
MAV06SR |
D |
6 |
1/2-14 |
46.0 |
27 |
17 |
9.1 |
9.1 |
MAV08SR |
D |
8 |
1/2-14 |
46.0 |
27 |
19 |
9.1 |
9.1 |
MAV10SR |
D |
10 |
1/2-14 |
47.0 |
27 |
22 |
9.1 |
9.1 |
MAV12SR |
D |
12 |
1/2-14 |
47.0 |
27 |
24 |
9.1 |
9.1 |
Note: MAV supplied as standard with PSR + M nut (EO assembled).
*BSPP pressure gauge connection requires seal. 1/4" replacement seal P/N: M25180
**BSPP pressure gauge connection requires seal. 1/4" replacement seal P/N: DKI1/4CFX, 1/2" replacement seal P/N: DKI1/2CFX.
