Parker XHX7 Orifice | In-Line Orifice Connectors

     Parker JIC / JIC Pressure Gauge Adapters (Type B)



    Parker JIC / ORB Orifice Fittings

    Part #: XHX7
    Manufacturer: Parker



    NPT Gauge / ORFS

    TUBE FITTING
    PART #

    END
    SIZE

    C
    HEX
    (in.)

    ORIFICE
    (in.)

    L
    (in.)

    Pressure
    (x 1,000 PSI)

    1 & 2
    (in.)

    Static
    -S

    Dynamic
    -S

    4 XHX7-S .015 Orifice

    1/4

    9/16

    .015

    1.10

    10.0

    5.0

    4 XHX7-S .031 Orifice

    1/4

    9/16

    .031

    1.10

    10.0

    5.0

    4 XHX7-S .047 Orifice

    1/4

    9/16

    .047

    1.10

    10.0

    5.0

    4 XHX7-S .062 Orifice

    1/4

    9/16

    .062

    1.10

    10.0

    5.0

    4 XHX7-S .078 Orifice

    1/4

    9/16

    .078

    1.10

    10.0

    5.0

    4 XHX7-S .094 Orifice

    1/4

    9/16

    .094

    1.10

    10.0

    5.0

    6 XHX7-S .015 Orifice

    3/8

    11/16

    .015

    1.18

    10.0

    5.0

    6 XHX7-S .031 Orifice

    3/8

    11/16

    .031

    1.18

    10.0

    5.0

    6 XHX7-S .047 Orifice

    3/8

    11/16

    .047

    1.18

    10.0

    5.0

    6 XHX7-S .062 Orifice

    3/8

    11/16

    .062

    1.18

    10.0

    5.0

    6 XHX7-S .078 Orifice

    3/8

    11/16

    .078

    1.18

    10.0

    5.0

    6 XHX7-S .094 Orifice

    3/8

    11/16

    .094

    1.18

    10.0

    5.0

    8 XHX7-S .015 Orifice

    1/2

    7/8

    .015

    1.32

    8.5

    5.0

    8 XHX7-S .031 Orifice

    1/2

    7/8

    .031

    1.32

    8.5

    5.0

    8 XHX7-S .047 Orifice

    1/2

    7/8

    .047

    1.32

    8.5

    5.0

    8 XHX7-S .062 Orifice

    1/2

    7/8

    .062

    1.32

    8.5

    5.0

    8 XHX7-S .078 Orifice

    1/2

    7/8

    .078

    1.32

    8.5

    5.0

    8 XHX7-S .094 Orifice

    1/2

    7/8

    .094

    1.32

    8.5

    5.0

    Parker also offers a line of orifice adapters that will replace a traditional port adapter (custom product).

    Related Information





    Orders & Quotes

    Orifice Fittings

    Orifice adapters are compact and cost effective way to pre-set, a specified orifice in specific hydraulic tube or hose line. Costly flow control valves can be eliminated or minimized in a system and hydraulic system maintenance managers can be assured that end users are not adjusting the factory established flow and speed characteristics of the hydraulic system.

    • 37° flare and ORFS configurations as standard
    • Three standard body sizes available: 1/4”, 3/8”, and 1/2”
    • Available in commonly accepted pre-set orifice sizes
    • Designed for permanent or temporary installation
    • Can be installed in-line into hydraulic system by simply connecting between hose swivel and adapter
    • Orifice size is permanently stamped on body
    • Can eliminate costly flow control valves

    Applications:

    • Fixed rotation speed for hydraulic motors
    • Fixed speed on cylinder extend or retract
