Parker G5EQ | SAE Port Block Elbow

TUBE FITTING
PART #

T5
STRAIGHT
THREAD

UN-2B

SAE
PORT
DASH

SIZE

FLANGE
SIZE

(in.)

A

(in.)

B

(in.)

D

(in.)

E

(in.)

K
DRILL
DIA.

(in.)

L

(in.)

M

(in.)

N

(in.)

T
THREAD

UNC-2B

DYNAMIC PRESSURE (x 1000 PSI)

-SX

O-RING FACE

FLAT FACE

SAE PORT / CODE 61 BLOCK FLANGE OR PAD

12G5EQ1B

12G5EQ1P

1-1/16-12

12

0.75

1.69

2.56

0.75

1.25

0.406

2.28

1.440

0.875

3/8-16

4.0

16G5EQ1B

16G5EQ1P

1-5/16-12

16

1.00

1.94

2.75

1.00

1.50

0.406

2.62

1.660

1.062

3/8-16

3.0

20G5EQ1B

20G5EQ1P

1-5/8-12

20

1.25

2.19

3.12

1.25

1.81

0.469

3.00

1.910

1.188

7/16-14

2.5

24G5EQ1B

24G5EQ1P

1-7/8-12

24

1.50

2.56

3.69

1.50

2.00

0.531

3.33

2.050

1.312

1/2-13

2.0

32G5EQ1B

32G5EQ1P

2-1/2-12

32

2.00

3.06

4.33

2.00

2.50

0.531

3.81

2.280

1.656

1/2-13

1.5

SAE PORT / CODE 62 BLOCK FLANGE OR PAD

12G5EQ2B

12G5EQ2P

1-1/16-12

12

0.75

1.94

2.75

0.75

1.50

0.406

2.62

1.660

1.062

3/8-16

5.0

16G5EQ2B

16G5EQ2P

1-5/16-12

16

1.00

2.19

3.12

1.00

1.81

0.469

3.00

1.910

1.188

7/16-14

4.0

20G5EQ2B

20G5EQ2P

1-5/8-12

20

1.25

2.56

3.69

1.25

2.00

0.531

3.32

2.050

1.312

1/2-13

3.5

24G5EQ2B

24G5EQ2P

1-7/8-12

24

1.50

3.06

4.33

1.50

2.50

0.656

3.81

2.280

1.656

5/8-11

3.5
