Parker | Hydraulic Hoses | GlobalCore™

Any Pressure...

    Any Project...

       One Solution!

Parker GlobalCore is a unified system of hoses designed to meet the most common working pressures in the industry.

GlobalCore can withstand the toughest conditions, providing the highest standards of performance and value while reducing inventory and part number complexity.

GlobalCore consists of six series of hoses: 187, 387, 487, 722, 787 and 797. Pairing the hoses with fittings is simple, as each hose uses either Parker's 43 or 77 series, which are available in a variety of configurations. Several cover options are available to best suit your hose's application.

• 1,000 psi constant working pressure in all sizes
• 1/2 ISO 18752 minimum bend radius
• Low force to flex for ease of installation
• Exceeds ISO 18752 performance specification (AC and AS)
• Synthetic rubber inner tube provides a wider range of fluid compatibility

• 3,000 psi constant working pressure in all sizes
• 1/2 ISO 18752 minimum bend radius
• Low force to flex for ease of installation
• Exceeds ISO 18752 performance specification (AC, BC and CC)
• Synthetic rubber inner tube provides a wider range of fluid compatibility

• 4,000 psi constant working pressure in all sizes
• 1/2 ISO 18752 minimum bend radius
• Low force to flex for ease of installation
• Exceeds ISO 18752 performance specification (AC, BC & CC)

• 4,000 psi constant working pressure in all sizes
• 1/2 ISO 18752 minimum bend radius
• Exceeds ISO 18752 performance specification (BC and CC)
• 4-spiral construction for longer life in high-impulse, heavy-duty cycle applications

• 5,000 psi constant working pressure in all sizes
• 1/2 ISO 18752 minimum bend radius
• Meets ISO 18752 performance specification (BC/DC)
• Nearly 30% smaller O.D by area than SAE spiral
• Twice the impulse life - tested to 2,000,000 cycles
• Flex impulse tested
• Less hose weight than SAE spiral

• 6,000 psi constant working pressure in all sizes
• 1/2 the bend radius of SAE spiral
• Meets ISO 18752 performance specification (BC/CC/DC)
• Nearly 30% smaller O.D by area than SAE spiral
• Twice the impulse life - tested to 2,000,000 cycles
• Flex impulse tested
• Less hose weight than SAE spiral
