Concrete Placement Hose | Parker 7236 Series

Concrete Placement Hose - Natural Rubber / SBR Tube - Series 7236


Series 7236 is a high pressure placement hose for dry and wet cement, concrete and plaster. The hose construction incorporates a thick static dissipating natural rubber/SBR blend tube that provides abrasion resistance, and a heavy wall that provides kink resistance. The SBR cover is resistant to abrasion and weathering. Series 7236 is available in 200-foot continuous lengths.

Parker Concrete Placement Hose Sizes & Specifications

  • Tube: Black natural rubber/SBR blend; static dissipating
  • Reinforcement: Multiple textile plies
  • Cover: Black natural rubber/SBR blend; wrapped finish
  • Temp. Range: -30°F to +150°F (-34°C to +66°C)
  • Brand Method: Black text on white stripe
  • Brand Example: PARKER SERIES 7236 PLASTER & CONCRETE HOSE 800 PSI MAX WP MADE IN USA (LOT#)
  • Design Factor: 3:1
  • Industry Standards: None applicable
  • Applications:  Abrasive materials, dry and wet cement, concrete, plaster.  Construction, general industrial
  • Vacuum: Not recommended
  • Compare to: Veyance Allcrete Textile
  • Packaging: Coils

Part Number

ID

Reinf Plies

OD

Approx Wt

Min Bend
Rad

Max Rec WP

Std Pack Qty

in

mm

in

mm

lbs/ft

kg/ft

in

mm

psi

bar

ft

7236-125800

1-1/4

31.8

4

1.882

47.8

0.78

0.35

9.0

228.6

800

55.2

100

7236-150800

1-1/2

38.1

4

2.212

56.2

1.01

0.46

12.0

304.8

800

55.2

100

7236-200800

2

50.8

4

2.762

70.2

1.38

0.63

24.0

609.6

800

55.2

100

7236-200800050

2

50.8

4

2.762

70.2

1.38

0.63

24.0

609.6

800

55.2

50




WARNINGS! „Couplings attached with bands or clamps may reduce the working pressure of the hose assembly to less than the maximum rated working pressure of the hose. Refer to the NAHAD Industrial Hose Assembly Guidelines.

„
