Series 7232 is a large diameter, flexible liquefied petroleum gas (LPG)/propane transfer hose for large volume bulk loading/unloading and vibration-resistant onboard vehicle connections. The hose meets all Underwriters Laboratories (UL21) and Canadian Gas Association (CGA Type I) requirements. The construction incorporates multiple braids of textile reinforcement for kink resistance and superior coupling retention. The perforated cover is resistant to mild chemicals, oil and ozone. Series 7232 is available in long lengths and factory-tested assemblies in popular configurations.

Series 7232 and DOT: LPG hose assemblies installed on on-road vehicles must meet Department of Transportation (DOT) requirements. Factory assemblies (all sizes) are pressure tested, one of the fittings is etched with a unique DOT certification number, and a document incorporating the identical certification number accompanies each assembly. Metal DOT identification bands are also available/attached for an additional charge at customer request.

Series 7232 and Natural Gas: The molecules of natural gas are small, enhancing their ability to permeate through standard rubber hose constructions. The permeation process is more rapid as the working pressure increases, and natural gas accumulates with potentially dangerous consquences. Series 7232 may be used for natural gas service, but ONLY under all the following conditions:

  • The application must be in a well-ventilated environment, outdoors or indoors with significant continuous air movement.
  • Series 7232 is not to replace fixed/rigid pipe where that material is more appropriate due to reduced permeation and overall strength and durability. Use rigid pipe, non-permeable tubing or hose with barrier constructions to convey natural gas whenever possible.

Series 7232 and Compressed Natural Gas (CNG): Series 7232 is not for use in any CNG application, including fuel dispensing, on-board vehicle fuel lines, or fuel transfer.

Series 7232 and Anhydrous Ammonia (NH3): Series 7232 is not for use with anhydrous ammonia.



TUBE Black nitrile
REINFORCEMENT Multiple textile braids
COVER

Black chloroprene; perforated wrapped finish

TEMPERATURE RANGE -40°F to 180°F (-40°C to 82°C) (Note: The hose construction is capable of this rating, but LP gas should NEVER be conveyed over 140°F/60°C)
DESIGN FACTOR 5:1
INDUSTRY STANDARDS UL21; CAN/CGA-8.1-M86 Type I; optional DOT factory hose assembly testing and marking also available
APPLICATIONS
  • LP gas, propane
  • Bulk loading/unloading, in-plant tank transfer, transport
  • Agriculture, commercial and residential heating, construction, general industrial
VACUUM Not recommended
COMPARE TO Boston Blackline (LPG); Gates LP350; Thermoid Type 65
PACKAGING Cartons, reels



Part #

ID (in) Reinf Braids
OD (in) Min Bend Rad (in) Max Rec WP (psi) Perm Cplg Rec*
7232-1252 1-1/4 2 1.815 12.0 350 HY
7232-1503K 1-1/2 2 2.156 14.0 350 43
7232-2003K 2 3 2.750 16.0 350 7661

 *Couplings: Refer to CrimpSource at www.safehose.com for coupling recommendations and crimp specifications.



LP Gas Hose - Factory Assemblies

Crimped-on Carbon Steel Couplings, Rigid Male NPT Thread x Rigid Male NPT Thread Cartons

Part # ID (in) Length (ft)
7232HY20MP-180 1-1/4 15
7232LA32NP-144 2 12
7232LA32NP-180 2 15
7232LA32NP-228 2 19
