PVC Industrial Hoses | Parker | NEXSPRAY PVC Spray Hose | 268 Series

Nexspray-U-202-203

Series 202/203 is a high pressure spray hose designed to handle diluted hydrocarbon-based chemicals, herbicides and pesticides. The longitudinally ribbed cover reduces drag and is resistant to abrasion, ultraviolet light and weathering.



TUBE Black urethane/PVC
REINFORCEMENT Multiple textile plies
COVER Green or yellow PVC; longitudinally ribbed finish
TEMPERATURE RANGE

25°F to 150°F (-5°C to 65°C)

Working pressures are at 68°F (20°C). Higher temperatures reduce the available working pressure.

INDUSTRY STANDARDS None applicable
APPLICATIONS
  • Chemicals, herbicides, pesticides, water
  • Agriculture, commercial lawn and garden
VACUUM Not recommended
PACKAGING Coils

Series 202 - NEXSPRAY U600, 600 PSI, Yellow Ribbed Cover

Part # ID (in) OD (in) Reinf Plies Max Rec WP @ 68°F (psi) Perm Cplg Rec
202-06002300 3/8 .655 4 600 *
202-06002400 3/8 .655 4 600 *
202-08002300 1/2 .840 4 600 *
202-08002400 1/2 .840 4 600 *
202-12002300 3/4 1.140 4 600 *

 * Couplings: Refer to CrimpSource at www.safehose.com for coupling recommendations and crimp specifications.


Series 203 - NEXPRAY U800, 800PSI, Green Ribbed Cover

Part # ID (in) OD (in) Reinf Plies Max Rec WP @ 68°F (psi) Perm Cplg Rec
03-06005300 3/8 .655 4 800 *
203-08005300 1/2 .840 4 800 *
203-10005300 5/8 .990 4 800 *
203-12005300 3/4 1.140 4 800 *

 * Couplings: Refer to CrimpSource at www.safehose.com for coupling recommendations and crimp specifications.



How to Order

  • Visit One of Our ParkerStores
  • Click on the quote button below.
 ASK QUESTION!  REQUEST QUOTE





IMPORTANT!
Hose and hose fittings series must be correctly matched. Using any fittings other than those specifically designated by the hose manufacturer for use with each specific hose can lead to hose assembly failure. Hose assembly failures have lead to damage, injury and death.
