PVC Industrial Hoses | Parker | NEXVA EVA Hose | 450 Series

Nexva-450

Series 450 is a medium pressure hose designed to handle chemicals such as anhydrous ammonia, herbicides, pesticides and water. The semi-translucent construction permits visual observation of materials being conveyed, and the durable construction is resistant to abrasion, ultraviolet light and weathering.

Note: Do not use for anhydrous ammonia delivery/transfer.



TUBE Semi-translucent natural ethyl vinyl acetate (EVA)
REINFORCEMENT Multiple textile plies
COVER Semi-translucent EVA
TEMPERATURE RANGE

-50°F to 125°F (-45°C to 52°C)

Working pressures are at 68°F (20°C). Higher temperatures reduce the available working pressure.

INDUSTRY STANDARDS RoHS
APPLICATIONS
  • Mild chemicals; anhydrous ammonia, herbicides, pesticides, water
  • Anhydrous ammonia applicator, light vacuum line, seed insertion, sight gauge
  • Agriculture, commercial lawn and garden
VACUUM Light
PACKAGING Coils



Part # ID (in) OD (in) Reinf Plies Max Rec WP @ 68°F (psi) Perm Cplg Rec
450-04006500 1/4 .390 2 300 *
450-06000300 3/8 .595 2 250 *
450-08000300 1/2 .720 2 250 *
450-10000300 5/8 .845 2 200 *
450-12000300 3/4 .970 2 150 *
450-16000200 1 1.310 2 150 *

* Couplings: Refer to CrimpSource at www.safehose.com for coupling recommendations and crimp specifications.
