Water Industrial Hoses | Parker | WILDCATTER® White Washdown Hose | 7360 Series


    HDW-7080


    Series 7360 is a low pressure washdown hose for hot water in cleaning applications where higher pressures are not required. The hose construction incorporates multiple plies of textile reinforcement that provides flexibility, and the white, non-marking cover is resistant to abrasion, heat and ozone.

    NOTE: Do not expose to fatty or oily foods.



    TUBE White SBR
    REINFORCEMENT Multiple textile plies
    COVER

    White SBR; wrapped finish
    TEMPERATURE RANGE

    -40°F to 212°F (-40°C to 100°C)

    DESIGN FACTOR 4:1
    INDUSTRY STANDARDS None applicable
    APPLICATIONS
    • Hot water
    • Breweries, dairies, food processing plants, general industrial, oil rigs, paper mills
    VACUUM Not recommended
    COMPARE TO Veyance Plicord Washdown
    PACKAGING Coils


    Part #

    		 ID (in) Reinf Plies
    		 OD (in) Min Bend Rad (in) Max Rec WP (psi) Perm Cplg Rec* Std Pack Qty (ft)
    7360-50150 1/2 2 1.008 4.0 150 *
    		 50
    7360-75150 3/4 2 1.250 6.0 150 * 50
    7360-75150100 3/4 2 1.250 6.0 150 * 100
    7360-100150 1 2 1.598 8.0 150 * 50
    7360-150150 1-1/2 4 2.125 18.0 150 * 50
    7360-200150 2 4 2.748 24.0 150 * 50

     *Couplings: Refer to CrimpSource at www.safehose.com for coupling recommendations and crimp specifications.
