Parker SCP01 Pressure Sensor Released

Parker’s Pneumatic division has informed us today about the introduction of a new pressure sensor – SCP01. SCP01 pressure sensors have a 4-20ma output enclosed in a stainless steel housing with an IP Rating of 67. This is a lower cost 4-20ma solution for high pressure circuits, than LED and multiple function programming options. SCP01 sensors can be used in either pneumatic or hydraulic applications.

Features:

• Electrical Output Options: 4-20ma analog output
• M12 X 1, 4 pin Electrical Connection
• Supply voltage 9-30 VDC
• Fluid Connection: 1/4 NPT male or 7/16-20UNF-2A, male SAE-4 with o-ring fluid connection

• Multiple Pressure Ranges:
  -14.5 to 250 psig
  0 to 1000 psig
  0 to 3000 psig
  0 to 5000 psig
  0 to 9000 psig

• Stainless steel body:
  Material - housing 304 SS
  Material - fitting 630 SS
• Sealing Material-Fluorocarbon
• Sensing element - Thin film (poly Si on SiO2)
• Compact construction
• Shock and vibration proof
• Resistant to pressure spikes
• Accuracy +/- 0.5% FS
• Protection class IP67 and CE marked

Posted by Marek Bobik
