Parker Air Preparation Products | Global FRLs | P31P Proportional Regulator
FEATURES
|
Part Numbers
Part Number | Description |
Port Size |
Flow* |
Max. Operating Pressure (psig) |
P31PA12AZ2V*1A |
2 bar (29 psig) mini proportional regulator, BSPP |
1/4" | 19 (40) | 3 (43.5) |
P31PA12AD2V*1A |
10 bar (145 psig) mini proportional regulator, BSPP |
1/4" | 19 (40) | 10.5 (152) |
P31PA22AZ2V*1A |
2 bar (29 psig) mini proportional regulator, BSPT |
1/4" | 19 (40) | 3 (43.5) |
P31PA22AD2V*1A | 10 bar (145 psig) mini proportional regulator, BSPT | 1/4" | 19 (40) | 10.5 (152) |
P31PA92AZ2V*1A | 2 bar (29 psig) mini proportional regulator, NPT |
1/4" | 19 (40) | 3 (43.5) |
P31PA92AD2V*1A | 10 bar (145 psig) mini proportional regulator, NPT | 1/4" | 19 (40) | 10.5 (152) |
* Output Signal. D= Digital PNP, P= PNP or 0-10V, N=NPN or 0-10V, M=4-20mA fixed.
Mounting Brackets and Accessories
Part Number | Description |
P3HKA00ML | L-Bracket mounting kit |
P3HKA00MC | Foot bracket mounting kit |
CB-M12-4P-2M | 2 mtr. cable with moulded straight M12x1 connector |
Technical Specifications
Flow Capacity: | 19 dm3/s (40 SCFM) |
Temperature Range: |
32°F to 122°F |
Pressure Control Range: |
0-2 bar (0-29 psig) 0-7 bar (0-101.5 psig) 0-10 bar (0-145 psig) |
Port Size: | 1/4" (BSPP, BSPT, NPT) |
Supply Voltage: |
24 VDC ± 10% |
Power Consumption: | Max. 1.1W with unloaded signal outputs |
Weight: | 0.64 lbs (0.29 kg) |
WARNING: These products can expose you to chemicals including lead and/or DEHP and/or carbon black, which are known to the State of California to cause cancer or birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
