| HUMIDITY SENSORS |
 |
| Body Seals |
Fluorocarbon & Nitrile |
| Housing Material |
Polycarbonate |
| Port |
1/4" Male NPTF |
| Wetted Parts Material |
Brass |
Working Pressure
|
0-150 psi |
| Max. Overload Pressure |
150 psi Max |
| Burst Pressure |
4x |
Accuracy (at 77°F / 25°C, 20% RH to 80% RH, at ambient pressure)
|
±5% RH Max |
Resolution (at 77°F / 25°C)
|
0.1% RH |
| Scan/Transmit Rate |
User Selectable |
| Response Time (from 33% to 75% RH) |
10 secs |
Ambient Temp Range (battery limited)
|
-4° to 167°F |
Operating Temperature (battery limited)
|
-4° to 167°F |
| Temperature Accuracy (from 14°F to 185°F) |
±1.0°F |
| Full Range Life Cycles |
> 1 million |
| Certifications |
FCC, IC, CE |
| Battery |
CR123A |
| IP Rating |
IP65 |
